CO2 Gas Regulator PRV – Wall Mounted 0–35 PSI Beer Regulator

CO2 Gas Regulator PRV – Wall Mounted 0–35 PSI Beer Regulator

The Wall Mounted CO2 Gas Regulator with PRV is a primary beverage gas regulator designed for controlling CO2 pressure in professional draught beer and beverage dispense systems.

The regulator reduces the incoming CO2 supply to an adjustable working pressure of 0–35 PSI, allowing the pressure to be set according to the requirements of the individual draught system.

Featuring dual pressure relief valves, a 3/8" push-fit outlet and a wall mounting bracket, it is ideal for permanent cellar, bar and brewery gas installations.

Wall Mounted CO2 Beer Gas Regulator

Unlike a bottle-mounted regulator, this version is designed to be secured to a wall or suitable fixed surface.

This can provide a cleaner and more accessible installation in professional cellars where gas cylinders and dispense equipment are permanently positioned.

The included mounting bracket keeps the regulator securely positioned while allowing straightforward access for pressure adjustment and servicing.

Key Features

• Wall mounted CO2 gas regulator
• Primary regulator for draught beer systems
• Single-stage pressure regulation
• Adjustable 0–35 PSI outlet pressure
• Designed for compatible CO2 beverage gas systems
• 3/8" push-fit gas outlet
• Dual pressure relief valves
• Wall mounting bracket included
• Suitable for professional cellar installations
• Suitable for draught beer and beverage systems

Adjustable 0–35 PSI Pressure

The regulator provides an adjustable outlet pressure from 0 to 35 PSI.

This allows the CO2 pressure to be set according to the requirements of the beverage and dispense installation.

The correct operating pressure can depend on factors including:

• Beverage type
• Keg requirements
• Storage temperature
• Carbonation level
• Beer line diameter and length
• Cooler configuration
• Tap and font arrangement

Always use the pressure recommended for the individual product and dispense system.

Dual Pressure Relief Valves

The regulator incorporates two pressure relief valves (PRVs) as part of its pressure management and safety design.

Pressure relief valves should never be blocked, modified or relied upon as a substitute for correct regulator installation and adjustment.

3/8" Push-Fit Outlet

The regulator is fitted with a 3/8" push-fit gas outlet, allowing connection to compatible 3/8" beverage gas pipework.

This makes it suitable for integration into professional cellar gas systems using standard 3/8" push-fit pipe and fittings.

Wall Mounting Bracket Included

A wall mounting bracket is supplied with the regulator.

Mounting the regulator to a suitable solid surface keeps it accessible while helping to keep cellar gas equipment and pipework organised.

Use appropriate fixings for the wall construction and installation.

Primary & Secondary Regulation

This regulator can provide the primary regulated CO2 supply for a draught dispense installation.

Where individual kegs require different pressures, compatible secondary regulator valves can be installed downstream.

A typical installation may be:

CO2 Supply → Wall Mounted Primary Regulator → Gas Pipe → Secondary Regulator → Keg Coupler

Suitable For

The Wall Mounted CO2 Gas Regulator is suitable for compatible beverage gas systems used in:

• Pubs
• Bars
• Breweries
• Brewery taprooms
• Restaurants
• Hotels
• Cellar installations
• Mobile bar installations
• Event bars
• Professional draught dispense systems

Specifications

• Regulator Type: Primary CO2 gas regulator
• Configuration: Wall mounted
• Gas: CO2
• Regulation: Single stage
• Adjustable Outlet Pressure: 0–35 PSI
• Outlet Connection: 3/8" push-fit
• Pressure Relief: Dual PRV
• Mounting Bracket: Included

Important

This regulator is intended for use with compatible beverage CO2 systems.

Always ensure the correct regulator, gas type and operating pressure are used for the individual draught system.

Gas cylinders and associated equipment operate under high pressure and should be installed and maintained by a competent person familiar with beverage gas systems.
